Shanghai ENJUE Machinery Equipment Co., Ltd is one of the most experienced manufacturers and suppliers of 20' mobile container tipper for loading in China. If you're going to buy custom 20' mobile container tipper for loading made in China, welcome to get more information from our factory. For price consultation, contact us.
Meet the ENJUE 20' Mobile Container Tipper - built exclusively for 20-foot standard containers.
It is tilting and loading fast. It weighs in real time. And it goes wherever you need it on site.
No fixed rails. No heavy infrastructure. Just a high-precision weighing system that monitors every kilogram as material flows into the container - giving you complete control over load accuracy, container utilization, and operational transparency.
Traditional bulk loading? Outdated. This is the new standard.
Core Functions and Advantages of Enjue mobile container tipper:
High-Efficiency Tilting Loading:
It can safely and securely clamp and rotate containers to the optimal angle (typically 0-90 degrees), and can load at 0-90 degrees, utilizing the gravity flow of materials for rapid and even loading.
This significantly reduces reliance on loaders, forklifts, and other machinery, and the frequent entry and exit of containers, increasing loading efficiency several times over.
Especially suitable for loading various bulk materials such as grains, feed, fertilizers, plastic granules, and mineral sands.
The 20' mobile container tipper for loading specifications for reference
| Item | Parameters | Datas |
|---|---|---|
| Basic Reference Info | (SWL) | 35T |
| Motor Power | 30Kw | |
| Working Power | 380V | |
| Protection Level | IP55 | |
| Hydraulic System | Working Pressure | 22MPa |
| Suitable | ISO Standard 20'container | |
| Hydraulic Cylinder Specifications (Piston/Piston rod) | ϕ160/ϕ90 mm | |
| Operation Performance | 90°Tilting time | <80S |
| Load Cell | 4 digital displays, maximum 80T | |
| Control Voltage | DC24V/AC220V | |
| Environmental Conditions | Working Temperature Range | -40°C ～ +40°C |
| Working Speed | 25m/s | |
| Operation Method | Control Operation Method | Gamepad/joystick/Wireless remote control |
| Dead Weight | Dead Weight of The Container Tipper | ≈9.5T |
| Other Chacterristic | Locking Mechanism | Manual operation, locked by a locking pin. |
| Support Structure | Support beam | |
| Weighing Device | Shaft-type load cell |
Integrated High-Precision Weighing System
Traditional bulk loading? You load, you hope, you pray it's under the limit.
The ENJUE 20' Mobile Container Tipper does it differently.
A high-precision weighing system sits at the core of every operation - tracking the exact weight of material inside the container in real time, from the first scoop to the last.
No more overloading. No more underloading. Every container is loaded to the precise weight that meets international shipping standards - and maximizes every kilogram of payload capacity.
And the data? It doesn't walk away when the job ends. It can be recorded, printed, or uploaded to your management system - giving you complete traceability and full control over your operations.
This isn't weighing. It's intelligence.
Key Technical Features of the 20' mobile container tipper for loading
It fits perfectly. Purpose-built for 20' ISO standard containers, with an automatic locking device that secures the container before a single grain is loaded.
It moves with purpose. A full hydraulic drive system delivers smooth, powerful operation - with tilting speed you can adjust on the fly.
It's built to outlast the job. The steel structure isn't just thick - it's optimized through finite element analysis, meaning every beam is exactly where it needs to be for maximum stability under heavy-duty conditions.
It thinks for you. One intelligent control cabinet handles everything - real-time weighing, tilting control, safety alarms - all through a simple, intuitive interface.
It protects everything. Limit switches. Overload protection. Emergency stop buttons-anti-tip devices. Multiple layers of safety so your people, your cargo, and your equipment are always covered.
Typical Application Scenarios of the mobile container tipper for loading
Ports and Logistics Centers: Containerization for bulk cargo exports and loading of return cargo after import unloading.
Grain and Agricultural Product Processing Enterprises: Containerized transportation of grains such as corn, wheat, and soybeans.
Chemical and Building Materials Industries: Standardized packaging and transshipment of materials such as fertilizers, resins, plastic granules, and feed.
Mining and Metallurgical Enterprises: Short-haul transportation and sea freight preparation for bulk materials such as mineral products and additives.
