Shanghai ENJUE Machinery Equipment Co., Ltd is one of the most experienced manufacturers and suppliers of electro-hydraulic orange peel grabs in China. If you're going to buy custom electro-hydraulic orange peel grabs made in China, welcome to get more information from our factory. For price consultation, contact us.
The electro-hydraulic orange peel grabs by ENJUE are engineered for continuous-duty operations where reliability, cycle efficiency, and structural durability are critical. Each unit is fully self-contained, integrating an electric motor with an internal hydraulic system, enabling seamless installation on overhead cranes, port cranes, ship cranes, and stationary systems without the need for external hydraulic circuits. Our product range covers capacities from 500 liters to 20,000 liters, making it suitable for applications ranging from light scrap handling to heavy bulk material handling.
In addition, our ENJUE electro-hydraulic multi-flap grab is purpose-built for handling irregular bulk materials. Its multi-jaw design, powered by heavy-duty hydraulic cylinders, delivers powerful grabbing force and smooth operation. Versatile enough for scrap steel, ore, coal, and more, with an optional 360° rotation function, it provides an efficient and reliable solution for bulk cargo handling across a wide range of industries.
parameters and drawing of electro-hydraulic orange peel grabs
| Rated Lifting Capacity | 5t / 10t / 20t / 30t (customizable) |
| Grab Bucket Type | Multi-jaw |
| Applicable Materials | Scrap steel, ore, coal, bulk cargo, waste, scrap metal, etc. |
| Hydraulic System | Electro-hydraulic drive with self-contained power pack |
| Driving Hydraulic Cylinder | Heavy-duty double-acting hydraulic cylinder |
| Working Pressure | 16–25 MPa (customizable) |
| Rotation Function | Optional ±360° electro-hydraulic slewing |
| Compatible Equipment | Overhead cranes, gantry cranes, crawler cranes, port quayside cranes/portal cranes |
Key features of electro-hydraulic orange peel grabs
Multi-Flap Structure
The multi-jaw body is fabricated from high-strength wear-resistant steel plates with replaceable cutting edges. This design prevents slipping and material loss when handling irregular materials.
Top Beam, Lifting Lugs
Compatible with standard crane hooks and wire ropes for direct installation. Interfaces are also reserved for retrofitting slewing devices when required.
Hydraulic Piping, Protection
High-pressure oil hoses are equipped with protective sheaths, providing anti-wear and anti-corrosion performance to withstand the high salt-fog environment of ports.
Electro-Hydraulic Power Pack
Electro-hydraulic drive with a built-in control unit supports both remote and cab operation.
Hydraulic Cylinder System of electro-hydraulic orange peel grabs
Heavy-duty Hydraulic Cylinders
Double-acting cylinders with bore and rod diameters customized to meet specific grapple force requirements. Featuring high thrust and impact resistance, they are well-suited for high-frequency opening and closing operations.
Multi-cylinder Synchronous Drive
Multiple cylinders are evenly distributed to ensure synchronized grab opening and closing, balanced force distribution, and no unbalanced-load deformation of the jaws.
High-pressure Sealing System
Imported seals provide wear resistance and leak prevention, ensuring long service life even under harsh port conditions.
Cylinder Mounting Structure
Hinged mounting with built-in cushioning protection eliminates impact during opening and closing, reducing structural fatigue.
Application Scenarios of electro-hydraulic orange peel grabs
Ports / Terminals: Handling of bulk cargo such as scrap steel, ore, coal, etc.
Steel Mills / Smelters: Handling of scrap steel, steel slag, and furnace charge
Waste / Solid Waste Treatment: Grabbing of municipal solid waste and industrial waste
Mines / Stockyards: Handling of irregular ore and bulk materials
