Shanghai ENJUE Machinery Equipment Co., Ltd is one of the most experienced manufacturers and suppliers of container lifting frame in China. If you're going to buy custom container lifting frame made in China, welcome to get more information from our factory. For price consultation, contact us.
The Enjue Container Lifting Frame is engineered to redefine efficiency in container logistics by eliminating the need for ground personnel to manually operate twist-locks. Designed for seamless integration with 20ft, 40ft, and custom 45ft containers, this system delivers unmatched precision and safety. Whether handling standard containers or adapting to non-containerized cargo via specialized lifting beams (available upon request), the Autoloc frame is a versatile powerhouse built for the rigors of industrial rigging.
Key Features of Our Container Lifting Frame
Fully Automated Twist-Lock Mechanism
Self-Actuating Bayonets: Four twist-lock bayonets engage or disengage simultaneously through a 90-degree rotation triggered by adjusting the tension of the included 4-legged sling. This eliminates manual intervention, reducing labor costs and human error.
Visual Confirmation System: Built-in indicator flags provide real-time feedback to crane operators. When the sling is slackened, red flags rotate 90 degrees, signaling that bayonets are securely locked or ready for release.
Robust Construction & Corrosion Resistance
N31000C Models: Treated with proprietary paint process, these frames offer exceptional durability against salt, chemicals, and abrasion, ensuring longevity in harsh environments.
Adaptability Beyond Containers
Modular Design: Compatible with specially adapted container lifting beams (on request), the system can lift non-standard loads such as heavy machinery, steel coils, or oversized equipment.
Size Options
Standard frames for 20ft and 40ft containers.
45ft container lifting frames available for specialized applications, expanding flexibility for unique project requirements.
Operational Workflow of the Container Lifting Frame
Positioning the Spreader
The crane operator lowers the Autolok frame onto the container, aligning the bayonets with the corner fittings.
Engaging the Twist-Locks
Once seated, the operator slackens the crane wire, causing the 4-legged sling to adjust tension. This action rotates the bayonets 90 degrees into the locked position, confirmed by the rotation of red indicator flags.
Safe Lifting
With bayonets securely engaged, the operator hoists the container. Clear visual indicators ensure all personnel maintain a safe distance during lift-off.
Releasing the Load
To disengage, the operator repeats the slackening process, rotating the bayonets back 90 degrees. The indicator flags reset, signaling safe removal of the frame.
Applications of the Container Lifting Frame
Port terminals and intermodal yards
Construction sites handling heavy equipment
Manufacturing facilities with non-containerized cargo
Military and disaster relief operations require rapid deployment
Why Choose Enjue Autolock Container Lifting Frame?
Labor Efficiency: Reduces ground crew dependency during twist-lock operations.
Safety First: Visual indicators and automated locking minimize risks of accidental disengagement or improper seating.
Future-Ready: Modular design supports evolving needs, from container handling to custom rigging projects.
